HR Series pump is horizontal, between bearing support, radially split, double volute, single stage, double stages or 3 stages, single stage single suction or double suction centrifugal pump. The pump type is mainly for all kinds of equipment in the high temperature, low temperature, high pressure and other important station development of centrifugal pump, according to the device pipeline demand arbitrary choice of pump inlet and outlet direction.

HT series hydraulic power recovery turbine through high pressure liquid driven turbine rotation to convert the pressure energy into the rotor kinetic energy driving equipment, so that the liquid in the device rich pressure can be recycled. All kinds of centrifugal pumps can be reformed into HPRT after the technical improvement of key parts.

OH-F horizontal cantilever pump is end suction, top discharge, single stage radial split, foot mounted processing pump, API code is OH1, suit to pumping clean or slightly polluted, chemical neutral or corrosive medium. OH-C horizontal cantilever pump is end suction, top discharge, single-stage radial split, centerline support processing pump, API code is OH2, suit to pumping clean or slightly polluted, chemical neutral or corrosive, low temperature or high temperature medium. OH series pump conforms to the American Petroleum Institute API610 10th/API610 11th design standard.

T-G series pump is a new generation of heavy load double-casing horizontal multistage centrifugal pump independently developed by our company, the inner core of the pump adopts segmental structure and is supported by both ends. Used for pumping all kinds of clean or particle, neutral or corrosive medium, especially for LPG, flammable, toxic, high temperature, high pressure liquid.
Flow Q：3~1200m3/h
Pressure P：42.0MPa
Head H：3600m
Temperature T：-80~+450℃

MA series pump is axial split, opposed impeller arrangement, volute type, horizontal, multistage, first impeller single or double suction centrifugal pump, suitable for conveying all kinds of clean or contain trace particles, neutral or corrosive medium, in conveying medium containing solid particles, particularly stable performance.
